Specifications
| AF Modes | Stills: One-Shot AF, Servo AF, AI Focus AF (with Scene Intelligent Auto), Manual Movie recording: One-Shot AF, Movie Servo AF, Manual |
| AF Point Selection | Automatic selection, Manual selection |
| AF System Points | Stills: Max. 6,072 selectable AF point positions / Up to 1,053 AF areas (auto selection) Movie recording: Max. 4,968 selectable AF point positions / Up to 819 AF areas (auto selection) |
| Built-in Flash | – |
| Closest Focusing Distance (cm) | – |
| Continuous Shooting Speed (Shots Per Sec) (Up To) | Mechanical shutter & Electronic 1st curtain: 12 Electronic shutter*: 20 *Lenses other than EF-S |
| Digital Zoom | – |
| Dimensions (Excl. Protrusions) (mm) (Approx.) | 138.4 × 97.5 × 88.4 |
| Drive System | – |
| Effective ISO | Stills: 100–102,400 (L:50, H:204,800) Movie: 100–25,600 (H:204,800) Canon Log movies: ISO 400–25,600 (H:204,800) HDR PQ movies: ISO 100–25,600 |
| Effective Pixels (Megapixels) | 20.1 |
| Exposure Compensation | ±3 stops in 1/3-stop or 1/2-stop increments AEB: ±3 stops in 1/3-stop or 1/2-stop increments |
| Eye Detection AF | One-Shot AF / Servo AF / Movie Servo AF (Human, cats, birds & dogs’ eye detection available) |
| Flash Modes | E-TTL II , Manual, Multi, Ext A, Ext M, CSP |
| Focal Length (35mm Equivalent) | – |
| Guide Number ISO 100 metres | – |
| Image Resolution | 5472×3648 (JPEG L/RAW/C-RAW/HEIF), 3648×2432 (HEIF, JPEG M), 2736×1824 (HEIF, JPEG S1), 2400×1600 (HEIF, JPEG S2) |
| Image Stablizer | Stills: In-body 5-axis image stabilisation Movie: In-body 5-axis electronic image stabilisation |
| LCD Monitor (Size) (Inch) | 3.0 |
| LCD Monitor Resolutions (dots) | 1,620,000 |
| Manual Focus | Yes |
| Memory Card Type | Supports 2 memory cards: SD, SDHC*, SDXC*, *UHS-I & UHS-II cards compatible |
| Metering Mode | Stills: Evaluative, Partial, Spot, Center-weighted average Movie: Evaluative (when faces are detected with [Face+Tracking]), Center-weighted average (when no faces are detected) |
| Movie Format | MP4 |
| Optical Zoom | – |
| Optional Power | AC Power (AC Adapter AC-E6N and DC Coupler DR-E6) |
| Peripheral Connections | SuperSpeed USB (Type-C), External microphone IN / Headphone terminal, HDMI micro (Type D), Remote control |
| Processor Type | DIGIC X |
| Sensor Size | Full-Frame CMOS |
| Shooting Modes | Stills: Scene Intelligent Auto, Flexible-priority AE, Program AE, Shutter-priority AE, Aperture-priority AE, Manual exposure, Bulb, Custom 1-3 Movie recording: Scene Intelligent Auto, Movie auto exposure, Movie manual exposure |
| Shutter Speed Range (Sec.) | Stills: Mechanical / Electronic 1st-curtain: 30 – 1/8000, Bulb Electronic: 0.5 – 1/8000Movie recording: 1/8 – 1/4000 |
| Silent Shutter | Available: Single / Continuous Shot |
| Standard Power Supply | LP-E6NH/LP-E6N/LP-E6 |
| Still Image Format | JPEG, HEIF, RAW, C-RAW, RAW + JPEG, C-RAW + JPEG, RAW + HEIF, C-RAW + HEIF |
| Viewfinder Coverage (Approx.) | 100% |
| Viewfinder Type | 0.5-inch OLED, 3.69million dots 119.88p Refresh Rate |
| Weight (g) (Including the battery and memory card) (Approx.) *For camera kits, weight includes kit lens(es). |
680 |
| White Balance | Auto (Ambience priority), Auto (White priority), Preset (Daylight, Shade, Cloudy, Tungsten light, White fluorescent light, Flash), Custom, Color temperature setting (approx. 2500–10000 K) White balance correction and white balance bracketing features provided * Flash color temperature information transmission possible |
| X-sync (sec.) | Mechanical shutter: 1/200 Electronic 1st curtain: 1/250 |
